Examples
# Display LDP LSP information for the public network.
<Sysname> display mpls ldp lsp
Status Flags: * - stale, L - liberal
Statistics:
FECs: 4 Ingress LSPs: 1 Transit LSPs: 1 Egress LSPs: 3
FEC In/Out Label Nexthop OutInterface
1.1.1.1/32 -/3 10.1.1.1 Vlan17
1151/3 10.1.1.1 Vlan20
2.2.2.2/32 3/-
-/1151(L)
10.1.1.0/24 1149/-
-/1149(L)
192.168.1.0/24 1150/-
-/1150(L)
Table 23 Command output
Field Descri
p
tion
Status Flags
LSP status:
• *—Stale, indicating the LSP is under a GR process.
• L—Liberal, indicating the LSP is not available.
Statistics
LSP statistics:
• FECs—Total number of FECs.
• Ingress LSPs—Number of LSPs that take the local device as the
ingress node.
• Transit LSPs—Number of LSPs that take the local device as a transit
node.
• Egress LSPs—Number of LSPs that take the local device as the egress
node.
FEC Forwarding equivalence class identified by an IP prefix.
In/Out Label Incoming/outgoing label.
Nexthop Next hop address for the FEC.
OutInterface Outgoing interface for the FEC.
Related commands
display mpls lsp
display mpls ldp parameter
Use display mpls ldp parameter to display LDP running parameters.
Syntax
display mpls ldp parameter [ vpn-instance vpn-instance-name ]
Views
Any view
