Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies an MPLS L3VPN instance by its name, a case-sensitive string
of 1 to 31 characters. The command displays the LDP running parameters for the specified VPN. If you
do not specify a VPN instance, the command displays the LDP running parameters for the public
network.
Examples
# Display LDP running parameters for the public network.
<Sysname> display mpls ldp parameter
Global Parameters:
Protocol Version : V1
Nonstop Routing : Off Graceful Restart : Off
Reconnect Time : 120 sec Forwarding State Hold Time: 360 sec
Instance Parameters:
Instance ID : 0 Instance State : Active
LSR ID : 0.0.0.0
Loop Detection : Off
Hop Count Limit : 32 Path Vector Limit : 32
Label Retention Mode: Liberal Label Distribution Control Mode: Ordered
IGP Sync Delay : 0 sec IGP Sync Delay on Restart : -
Table 24 Command output
Field Descri
p
tion
Global Parameters Global parameters for all LDP-enabled networks.
Protocol Version LDP protocol version.
Nonstop Routing Nonstop routing function (not supported).
Graceful Restart
Whether the GR function is enabled.
• On—Enabled.
• Off—Disabled.
Reconnect Time Value of the Reconnect timer, in seconds.
Forwarding State Hold Time Value of the MPLS Forwarding State Holding timer, in seconds.
Instance Parameters Running parameters for a specific VPN instance or public network.
Instance ID VPN instance ID. For the public network, this field displays 0.
Instance State LDP status in the VPN instance, Active or Inactive.
LSR ID LSR ID of the local device.
Loop Detection
Whether loop detection is enabled.
• On—Enabled.
• Off—Disabled.
Hop Count Limit Hop count limit specified for loop detection.
Path Vector Limit Path Vector length limit specified for loop detection.
