R21xx-HP FlexFabric 11900 MPLS Command Reference

55
Field Descri
p
tion
Label Retention Mode The device supports only the Liberal mode.
IGP Sync Delay
Delay time (in seconds) that LDP must wait before it notifies IGP of an
LDP session-up event (not supported).
IGP Sync Delay on Restart
Delay time (in seconds) that LDP must wait before it notifies IGP of an
LDP session-up event in case of LDP restart (not supported).
display mpls ldp peer
Use display mpls ldp peer to display the LDP peer and session information.
Syntax
display mpls ldp peer [ vpn-instance vpn-instance-name ] [ peer-lsr-id ] [ verbose ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies an MPLS L3VPN instance by its name, a case-sensitive string
of 1 to 31 characters. The command displays LDP peer and session information for the specified VPN. If
you do not specify a VPN instance, the command displays the LDP peer and session information of the
public network.
peer peer-lsr-id: Specifies an LDP peer by its LSR ID. If you do not specify this option, the command
displays all LDP peers and related session information.
verbose: Displays detailed LDP peer and session information. If you do not specify this keyword, the
command displays brief LDP peer and session information.
Examples
# Display brief information about all LDP peers and LDP sessions for the public network.
<Sysname> display mpls ldp peer
Total number of peers: 1
Peer LDP ID State LAM Role GR MD5 KA Sent/Rcvd
2.2.2.9:0 Operational DU Passive Off Off 39/39
Table 25 Command output
Field Descri
p
tion
Peer LDP ID LDP identifier of the peer.
State
State of the LDP session between the local LSR and the peer:
• Non Existent—No TCP connection is established.
• Initialized—A TCP connection has been established.
• OpenRecv—LDP has received an acceptable initialization message.
• OpenSent—LDP has sent an initialization message.
• Operational—An LDP session has been established.
