Field Descri
p
tion
TCP connection
TCP connection information of the session, including the IP addresses and
port numbers used by both ends of the TCP connection, and whether MD5
authentication is enabled for the TCP connection. If MD5 authentication is
enabled, MD5 On is displayed. If MD5 is not enabled, this field is blank.
Session State
State of the LDP session:
• Non Existent—No TCP connection is established.
• Initialized—A TCP connection has been established.
• OpenRecv—LDP has received an acceptable initialization message.
• OpenSent—LDP has sent an initialization message.
• Operational—An LDP session has been established.
Session Role Role the local LSR in the session, Active or Passive.
Session Up time Duration of the session in Operational state.
Max PDU Length
Maximum PDU length negotiated, in bytes.
Local—Maximum PDU length (in bytes) on the local LSR.
Peer—Maximum PDU length (in bytes) on the peer.
Keepalive Time
Keepalive time negotiated, in seconds.
Local—Locally configured Keepalive holding time in seconds.
Peer—Keepalive holding time (in seconds) configured on the peer.
Keepalive Interval Current Keepalive interval in seconds.
Msgs Sent/Rcvd Total number of LDP messages sent and received.
KA Sent/Rcvd Total number of Keepalive messages sent and received.
Label Adv Mode
Label advertisement mode negotiated. The device only supports the DU
mode.
Graceful Restart
Indicates whether GR is enabled on the peer.
• On—Enabled.
• Off—Disabled.
Reconnect Time Reconnect time negotiated, in seconds.
Recovery Time Recovery time (in seconds) carried in packets sent by the peer.
Loop Detection
Whether loop detection is enabled on the peer.
• On—Enabled.
• Off—Disabled.
Path Vector Limit Maximum Path Vector length configured on the peer.
Discovery Sources Discovery source of the LDP peer.
