Field Descri
p
tion
Targeted Hello
LDP peer discovered by the extended discovery mechanism.
• The address before -> (100.100.100.17 in this example) is the local LSR
ID.
• The address after -> (100.100.100.20 in this example) is the LSR ID of
the peer.
• (Active) indicates that the local LSR is the active end. It actively sends
Targeted Hellos to its peer.
• (Passive) indicates that the local LSR is the passive end. It passively
responds to the Targeted Hellos from its peer.
• (Active, Passive) indicates that the local LSR acts as both the active end
and the passive end.
Ethernet1/2
Interface running LDP basic discovery. The device discovers the LDP peer
by sending Link Hellos out of the interface.
Hello Hold Time Hello hold time negotiated, in seconds.
Hello Interval Current Hello interval in milliseconds.
Label Acceptance Policy
Label acceptance policy used to filter label mappings received from the
peer.
Session Protection
Whether session protection is enabled.
• On—Enabled.
• Off—Disabled.
State
Session protection state:
• Incomplete—Session protection is not ready.
• Ready—Session protection is ready.
• Protecting—The session is under protection.
Duration
Local session protection duration in seconds.
Infinite indicates that session protection takes effect permanently.
Holdup time remaining
Remaining time of the session hold timer, in seconds.
This field is displayed only when the session protection state is Protecting.
A value of Infinite indicates that session protection takes effect
permanently.
Addresses received from peer IP addresses received from the peer.
display mpls ldp summary
Use display mpls ldp summary to display LDP summary information.
Syntax
display mpls ldp summary [ all | vpn-instance vpn-instance-name ]
Views
Any view
Predefined user roles
network-admin
network-operator
