Parameters
all: Displays LDP summary information for the public network and all VPN instances.
vpn-instance vpn-instance-name: Displays LDP summary information for the specified VPN. The
vpn-instance-name is a case-sensitive string of 1 to 31 characters.
Usage guidelines
If you execute this command without any parameters, the command displays LDP summary information
for the public network.
Examples
# Display LDP summary information for the public network.
<Sysname> display mpls ldp summary
Global Information:
Memory State : Normal
VPN Instance Name : Public
Instance ID : 0
Instance State : Active
Interfaces : 1 (1 active)
Targeted Peers : 0
Adjacencies : 1
Peers : 1
Operational : 1 (0 GR)
OpenSent : 0
OpenRecv : 0
Initialized : 0
Non-Existent: 0
Table 27 Command output
Field Descri
p
tion
Memory State
Memory state:
• Normal—The memory is normal.
• Minor—The memory has a minor alarm.
• Severe—The memory has a severe alarm.
• Critical—The memory has a critical alarm.
Discarded Hellos
Number of Hellos discarded when the memory is in an alarm state. If no Hello
is discarded, this filed is not displayed.
Instance ID VPN instance identifier. A value of 0 represents the public network.
Instance State LDP status in the VPN instance, Active or Inactive.
Interfaces
Number of interfaces enabled with LDP.
active: Number of interfaces running LDP.
Targeted Peers
Number of peers discovered by the LDP extended discovery mechanism,
including the manually specified peers and the automatically established
peers.
Adjacencies Number of Hello adjacencies.
Peers Total number of peers.
