R21xx-HP FlexFabric 11900 MPLS Command Reference

80
Parameters
vpn-instance vpn-instance-name: Specifies a VPN instance by its name, a case-sensitive string of 1 to 31
characters. If no VPN instance is specified, this command displays BGP VPNv4 peer group information
for the public network.
group-name: Specifies a peer group by its name, a case-sensitive string of 1 to 47 characters. If no peer
group is specified, this command displays all peer groups.
Examples
# Display all BGP VPNv4 peer groups for the public network.
<Sysname> display bgp group vpnv4
BGP peer group: group1
Remote AS number: not specified
Type: external
Members:
10.1.1.1
# Display information about the BGP VPNv4 peer group named group1.
<Sysname> display bgp group vpnv4 group1
BGP peer group: group1
Remote AS: 600
Type: external
Maximum number of prefixes allowed: 4294967295
Threshold: 75%
Configured hold time: 180 seconds
Keepalive time: 60 seconds
Minimum time between advertisements: 30 seconds
Peer preferred value: 0
Routing policy configured:
No routing policy is configured
Members:
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
2.2.2.2 600 0 0 0 0 00:00:05 Idle
Table 30 Command output
Field Descri
p
tion
BGP peer-group Name of the BGP peer group.
Remote AS AS number of the peer group.
Type
Type of the BGP peer group:
• External—EBGP peer group.
• Internal—IBGP peer group.
Maximum number of prefixes allowed
Maximum number of routes that can be learned from
the peer group.
