R21xx-HP FlexFabric 11900 MPLS Command Reference

81
Field Descri
p
tion
Threshold
Warning threshold. When the percentage of received
route prefixes to the maximum number of routes
reaches this threshold, the device generates a prompt.
Configured hold time Configured hold time in seconds.
Keepalive time Keepalive interval in seconds.
Minimum time between advertisements Minimum time between advertisements.
Peer Preferred Value Preferred value for routes received from the peer.
Routing policy configured Routing policy configured for the peer group.
Members Peers in the peer group.
Peer IPv4 address of the peer.
AS AS number of the peer group.
MsgRcvd Number of messages received.
MsgSent Number of messages sent.
OutQ Number of messages waiting to be sent to the peer.
PrefRcv Number of prefixes received.
Up/Down Duration of the BGP session in the current state.
State State of the peer.
display bgp peer vpnv4
Use display bgp peer vpnv4 to display information about BGP VPNv4 peers.
Syntax
display bgp peer vpnv4 [ vpn-instance vpn-instance-name ] [ group-name log-info | ip-address { log-info
| verbose } | verbose ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies a VPN instance by its name, a case-sensitive string of 1 to 31
characters. If no VPN instance is specified, this command displays BGP VPNv4 peer information for the
public network.
group-name: Displays peers in the specified peer group. The group name is a case-sensitive string of 1
to 47 characters.
ip-address: Specifies a BGP VPNv4 peer.
log-info: Displays log information.
verbose: Displays detailed information.
