Usage guidelines
With no parameters specified, this command displays brief information about all BGP VPNv4 peers.
Examples
# Display brief information about BGP VPNv4 peers for the public network.
<Sysname> display bgp peer vpnv4
BGP local router ID: 1.1.1.9
Local AS number: 100
Total number of peers: 2 Peers in established state: 1
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
3.3.3.9 100 50 51 0 2 00:37:19 Established
Table 31 Command output
Field Descri
p
tion
BGP Local router ID Router ID of the local BGP router.
Local AS number Local AS number.
Total number of peers Total number of peers.
Peers in established state Number of peers in the state of established.
Peer IP address of the peer.
AS AS number of the peer.
MsgRcvd Number of messages received.
MsgSent Number of messages sent.
OutQ Number of messages waiting to be sent to the peer.
PrefRcv Number of received prefixes.
Up/Down Duration of the BGP session in the current state.
State State of the peer.
# Display detailed information about BGP VPNv4 peer 10.1.1.1.
<Sysname> display bgp peer vpnv4 10.1.1.1 verbose
Peer: 10.1.1.1 Local: 192.168.1.136
Type: EBGP link
BGP version 4, remote router ID 192.168.1.135
BGP current state: Established, Up for 00h01m25s
BGP current event: KATimerExpired
BGP last state: OpenConfirm
Port: Local - 179 Remote - 1049
Configured: Active Hold Time: 180 sec Keepalive Time: 60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec Keepalive Time: 60 sec
Peer optional capabilities:
Peer support BGP multi-protocol extended
