R21xx-HP FlexFabric 11900 MPLS Command Reference

83
Peer support BGP route refresh capability
Peer support BGP route AS4 capability
Address family IPv4 Unicast: received
Address family VPNv4: advertised and received
Received: Total 4 messages, Update messages 1
Sent: Total 17 messages, Update messages 1
Maximum allowed prefix number: 4294967295
Threshold: 75%
Minimum time between advertisements is 30 seconds
Optional capabilities:
Multi-protocol extended capability has been enabled
Route refresh capability has been enabled
Connect-interface has been configured
Peer Preferred Value: 0
BFD: Enabled
Routing policy configured:
No routing policy is configured
Table 32 Command output
Field Descri
p
tion
Peer IP address of the peer.
Local IP address of the local router.
Type BGP link type: IBGP link or EBGP link.
BGP version BGP version of the peer.
remote router ID Router ID of the peer.
BGP current state Current state of the BGP session.
Up for Duration since the peer was established.
BGP current event Current event of the BGP session.
BGP last state
State that the BGP session was in before transitioning
to the current state.
Port Local and remote ports of the BGP session.
Configured
Settings of the local timers, including the active hold
interval and keepalive interval.
Received Received active hold interval.
Negotiated
Negotiated active hold interval and keepalive
interval.
Peer optional capabilities Optional capabilities of the peer.
Peer support bgp multi-protocol extended The peer supports multiprotocol extension.
Peer support bgp route refresh capability The peer supports route refresh capability.
Peer support bgp route AS4 capability The peer supports 4-byte AS number capability.
Address family IPv4 Unicast IPv4 unicast family capability.
