84
Field Descri
p
tion
Received
Total number of received messages and the number of
received update messages.
Sent
Total number of sent messages and the number of sent
update messages.
Maximum allowed prefix number
Maximum number of routes that can be learned from
the peer.
Threshold
Warning threshold. When the percentage of the
number of the received route prefixes to the maximum
number of routes supported reaches this threshold, the
device generates a prompt.
Optional capabilities Local optional capabilities.
Peer Preferred Value Preferred value for the routes from the peer.
BFD Indicates whether BFD is enabled for the peer.
# Display log information for the BGP VPNv4 peer 10.1.1.1.
<Sysname> display bgp peer vpnv4 10.1.1.1 log-info
Peer: 10.1.1.1
Date Time State Notification
Error/SubError
21-Nov-2011 12:36:58 Up
21-Nov-2011 12:22:29 Down Send notification with error 6/6
Cease/Other Configuration Change
21-Nov-2011 12:07:09 Up
display bgp routing-table ipv4 unicast inlabel
Use display bgp routing-table ipv4 unicast inlabel to display incoming labels for BGP IPv4 unicast
routes.
Syntax
display bgp routing-table ipv4 [ unicast ] [ vpn-instance vpn-instance-name ] inlabel
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies a VPN instance by its name, a case-sensitive string of 1 to 31
characters. If no VPN instance is specified, this command displays incoming labels for BGP IPv4 unicast
routes on the public network.
