Route distinguisher: 100:1(vpn1)
Total number of routes: 6
Network NextHop MED LocPrf PrefVal Path/Ogn
* > 10.1.1.0/24 10.1.1.2 0 32768 ?
* e 10.1.1.1 0 0 65410?
* > 10.1.1.2/32 127.0.0.1 0 32768 ?
* >i 10.3.1.0/24 3.3.3.9 0 100 0 ?
* >e 192.168.1.0 10.1.1.1 0 0 65410?
* i 3.3.3.9 0 100 0 65420?
Table 35 Command output
Field Descri
p
tion
BGP Local router ID Router ID of the local BGP router.
Status codes
Route status codes:
• * - valid—Valid route.
• > - best—Common best route.
• d – damped—Route damped for route flap.
• h - history—History route.
• i - internal—Internal route.
• e - external—External route.
• s - suppressed—Suppressed route.
• S - Stale—Stale route.
Origin
Route origin:
• i—IGP, originated in the AS. The origin of
summary routes and routes advertised by the
network command is IGP.
• e—EGP, learned through EGP.
• ?—Incomplete. The origin of routes redistributed
from IGP protocols is Incomplete.
Total number of routes from all PEs Total number of VPNv4 routes from all PEs.
Network Network address.
NextHop Address of the next hop.
MED MED value.
LocPrf Local preference value.
PrefVal Preferred value.
Path/Ogn AS_PATH and Origin attributes.
# Display detailed information about the BGP VPNv4 route destined for 10.3.1.0/24.
<Sysname> display bgp routing-table vpnv4 10.3.1.0 24
BGP local router ID: 1.1.1.9
Local AS number: 100
