3. Add member ports for this PVLAN.
Note – If VLAN tagging is turned off for a port, and that port’s default VLAN (PVID) is different
than the VLAN to which the port is being added, you will be asked to confirm changing the PVID
to the current VLAN, as shown in the example.
4. Configure VLAN tagging for ports.
5. Enable the PVLAN.
>> VLAN 2 Protocol 1# add 1
Port 1 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 2 [y/n]: y
Current ports for VLAN 2: empty
Current ports for VLAN 1, Protocol 3: empty
Pending new ports for VLAN 2: 1
Pending new ports for VLAN 2, Protocol 1: 1
>> VLAN 2 Protocol 1# add 20
Port 20 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 2 [y/n]: y
Current ports for VLAN 2: empty
Current ports for VLAN 1, Protocol 2: empty
Pending new ports for VLAN 2: 1 20
Pending new ports for VLAN 2, Protocol 1: 1 20
>> VLAN 2 Protocol 1# /cfg/port 1/tag ena (Enable tagging on port)
Current VLAN tag support: disabled
New VLAN tag support: enabled
Port 1 changed to tagged.
>> Port 1# /cfg/l2/vlan 2/pvlan 1/tagpvl (Enable PVLAN tagging)
Enter port to be tagged: 1
Ena/Dis pvlan tag: ena
Current status: disabled
New status: enabled
WARN: Tagging status of Port 1 in VLAN 2 will be changed for
all protocols.
Confirm changing port's pvlan tagging status [y/n]: y
>> VLAN 2 Protocol 1# ena (Enable protocol-based VLAN)
Current status: disabled
New status: enabled
>> VLAN 2 Protocol 1# apply (Apply the configuration)
>> VLAN 2 Protocol 1# save (Save your changes)
