BMD00113, September 2009 109
CHAPTER 5
Spanning Tree Protocol
When multiple paths exist on a network, Spanning Tree Protocol (STP) allows the switch to
determine the most efficient path. The following topics are discussed in this chapter:
“STP Overview” on page 109
“Bridge Protocol Data Units (BPDUs)” on page 110
“Spanning Tree Group Configuration Guidelines” on page 112
“Multiple Spanning Trees” on page 115
“Port Fast Forwarding” on page 118
“Fast Uplink Convergence” on page 118
“Hot Links” on page 119
STP Overview
Spanning Tree Protocol (STP) detects and eliminates logical loops in a bridged or switched
network. When multiple paths exist, STP configures the network so that a switch uses only the most
efficient path. If that path fails, Spanning Tree automatically sets up another active path on the
network to sustain network operations.
The HP GbE2c Ethernet Blade Switch (GbE2c) supports IEEE 802.1D Spanning Tree Protocol. It is
compatible with PVST+ by configuring each STP Group in different STP instances.
Note – The GbE2c also supports IEEE 802.1w Rapid Spanning Tree Protocol, and IEEE 802.1s
Multiple Spanning Tree Protocol. For more information, see Chapter 6, “Rapid Spanning Tree
Protocol/Multiple Spanning Tree Protocol.”
