BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 7: Link Layer Discovery Protocol 133
LLDP Receive Features
Types of Information Received
When the LLDP receive option is enabled on a port (see “Enabling or Disabling LLDP” on page 128),
the port may received the following types of information from LLDP-capable remote systems:
Chassis Information
Port Information
LLDP Time-to-Live
Port Description
System Name
System Description
System Capabilities Supported/Enabled
Remote Management Address
The GbE2c stores the collected LLDP information in the MIB. Each remote LLDP-capable device
is responsible for transmitting regular LLDP updates. If the received updates contain LLDP
information changes (to port state, configuration, LLDP MIB structures, deletion), the switch will
set a change flag within the MIB for convenient notification to SNMP-based management systems.
Viewing Remote Device Information
LLDP information collected from neighboring systems can be viewed in numerous ways:
Using a centrally-connected LLDP analysis server
Using an SNMP agent to examine the GbE2c MIB
Using the GbE2c Browser-Based Interface (BBI)
Using CLI or isCLI commands on the GbE2c
Using the CLI, the following command displays remote LLDP information:
To view a summary of remote information, omit the Index number parameter. For example:
>> # /info/l2/lldp/remodev [<index number>]
>> # /info/l2/lldp/remodev
LLDP Remote Devices Information
LocalPort | Index | Remote Chassis ID | Remote Port | Remote System Name
----------|-------|------------------------|-------------|----------------
17 |1 |001765fb2800 |17 |BLADE2
18 |2 |001765fb2800 |18 |BLADE2
