BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 7: Link Layer Discovery Protocol 135
LLDP Example Configuration
1. Turn LLDP on globally.
2. Set the global LLDP timer features.
3. Set LLDP options for each port.
4. Enable syslog reporting.
5. Apply and Save the configuration.
6. Verify the configuration settings:
7. View remote device information as needed.
>> # /cfg/l2/lldp/on
>> LLDP# msgtxint 30
(Schedule transmit every 30 seconds)
>> LLDP# txdelay 2 (Never more often than 2 seconds)
>> LLDP# msgtxhld 4 (Hold on remote side for 4 intervals)
>> LLDP# redelay 2 (Wait 2 seconds after reinitialization)
>> LLDP# notifint 5 (Minimum 5 seconds between traps)
>> LLDP# port <n> (Select a switch port)
>> LLDP Port# admstat tx_rx (Transmit and receive LLDP)
>> LLDP Port# snmptrap ena (Enable SNMP trap notifications)
>> LLDP Port# tlv/all ena (Transmit all optional information)
>> # /cfg/sys/syslog/log lldp ena
>> # /cfg/l2/lldp/cur
>> # /info/l2/lldp/remodev
or
>> # /info/l2/lldp/remodev <index number>
