BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 8: Quality of Service 141
Summary of ACL Actions
Actions determine how the traffic is treated. The GbE2c QoS actions include the following:
Pass or Drop
Re-mark a new DiffServ Code Point (DSCP)
Re-mark the 802.1p field
Set the COS queue
ACL Order of Precedence
When multiple ACLs are assigned to a port, the order in which the ACLs are applied to port traffic
(or whether they are applied at all) depends on the following factors:
The precedence group in which the ACL resides;
The ACL number;
Whether a prior ACL in the precedence group is also matched;
And whether the ACL action is compatible with preceding ACLs.
ACLs are divided into Precedence Groups, as shown in the following table. Each Precedence Group
provides a different set of packet classifiers for the ACLs within the Precedence Group.
Table 19 ACI Precedence Groups
Precedence Group Member ACLs Supported Packet Classifiers Priority Level
Precedence Group 1 ACL 1 – ACL 127 Destination MAC address
Source IP address
TCP source port
TCP destination port
Packet format
Highest
Precedence Group 2 ACL 128 – ACL 254 Destination MAC address
Destination IP address
Ethernet type
VLAN ID
802.1p
Packet format
