BLADE OS 5.1 Application Guide
142 Chapter 8: Quality of Service BMD00113, September 2009
Note – Precedence Groups are not related to ACL Groups.
The switch processes each precedence group in numeric sequence; Precedence group 1 is evaluated
first, followed by precedence group 2, and so on.
Within each precedence group, ACLs that are assigned to the port are processed in numeric
sequence, based on ACL number. Lower-numbered ACLs take precedence over higher-numbered
ACLs. For example, ACL 1 (if assigned to the port) is evaluated first and has top priority within
precedence group 1.
Precedence Group 3 ACL 255 – ACL 381 Source MAC address
Source IP address
Ethernet type
VLAN ID
802.1p
Packet format
Precedence Group 4 ACL 382 – ACL 508 Source IP Address
Destination IP Address
IP protocol
TCP source port
TCP destination port
TCP flags
IP Type of Service
Egress port
Precedence Group 5 ACL 509 – ACL 635 Source MAC address
Destination MAC address
Ethernet type
VLAN ID
802.1p
Packet format
Precedence Group 6 ACL 636 – ACL 762 Source MAC address
Destination MAC address
Ethernet Type
VLAN ID
802.1p
Packet Format
Lowest
Table 19 ACI Precedence Groups
Precedence Group Member ACLs Supported Packet Classifiers Priority Level
