BLADE OS 5.1 Application Guide
150 Chapter 8: Quality of Service BMD00113, September 2009
QoS Levels
Table 20 shows the default service levels provided by the GbE2c, listed from highest to lowest
importance:
Table 20 Default QoS Service Levels
Service Level Default PHB 802.1p Priority
Critical CS7 7
Network Control CS6 6
Premium EF, CS5 5
Platinum AF41, AF42, AF43, CS4 4
Gold AF31, AF32, AF33, CS3 3
Silver AF21, AF22, AF23, CS2 2
Bronze AF11, AF12, AF13, CS1 1
Standard DF, CS0 0
