BLADE OS 5.1 Application Guide
152 Chapter 8: Quality of Service BMD00113, September 2009
Use the /cfg/qos/8021p/cur command to display the mapping between 802.1p values, Class
of Service queues (COSq), and COSq scheduling weights:
802.1p Configuration Example
1. Configure a port’s default 802.1p priority.
2. Map the 802.1p priority value to a COS queue and set the COS queue scheduling weight.
3. Apply and save the configuration.
>> Main# /cfg/qos/8021p/cur
Current priority to COS queue configuration:
Number of COSq: 2
Priority COSq Weight
-------- ---- ------
001
101
201
301
412
512
612
712
>> Main# cfg/port 20 (Select port)
>> Port 20# 8021ppri (Set port’s default 802.1p priority)
Current 802.1p priority: 0
Enter new 802.1p priority [0-7]: 1
>> Port 20# /cfg/qos/8021p (Select 802.1p menu)
>> 802.1p# priq (Set COS queue assignments)
Enter priority [0-7]: 1
Current COS queue (for priority 1): 0
Enter new COS queue (for priority 1) [0-1]: 1
>> 802.1p# qweight (Set COS queue weights)
Enter COS queue [0-1]: 1
Current weight (for COS queue 1): 3
Enter new weight (for COS queue 1) [0-15]: 10
>> 802.1p# apply
>> 802.1p# save
