BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 9: Basic IP Routing 163
Each time you add a port to a VLAN, you may get the following prompt:
Enter y to set the default Port VLAN ID (PVID) for the port.
3. Add each IP interface to the appropriate VLAN.
Now that the ports are separated into three VLANs, the IP interface for each subnet must be placed
in the appropriate VLAN. From Table 23 on page 162, the settings are made as follows:
4. Apply and verify the configuration.
Examine the resulting information. If any settings are incorrect, make the appropriate changes.
5. Save your new configuration changes.
Port 1 is an untagged port and its current PVID is 1.
Confirm changing PVID from 1 to 2 [y/n]?
>> VLAN 3# /cfg/l3/if 1 (Select IP interface 1 for def. routers)
>> IP Interface 1# vlan 2 (Set to VLAN 2)
>> IP Interface 1# ../if 2 (Select IP interface 2 for first floor)
>> IP Interface 2# vlan 1 (Set to VLAN 1)
>> IP Interface 2# ../if 3 (Select IP interface 3 for second floor)
>> IP Interface 3# vlan 1 (Set to VLAN 1)
>> IP Interface 3# ../if 4 (Select IP interface 4 for servers)
>> IP Interface 4# vlan 3 (Set to VLAN 3)
>> IP Interface 5# apply (Make your changes active)
>> IP Interface 5# /info/l2/vlan (View current VLAN information)
>> Information# port (View current port information)
>> Information# save (Save for restore after reboot)
