BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 9: Basic IP Routing 171
Configuring ServerMobility on the Switch
Perform the following steps to configure the ServerMobility feature:
1. Turn on BOOTP Relay.
2. Turn on the ServerMobility feature, and add ports.
3. If desired, enable automatic recovery and configure backup Server Mobility ports.
4. Apply and save the configuration.
>> /cfg/l3/bootp/on
>> Bootstrap Protocol Relay# addr 10.10.1.1
Current bootp server: 0.0.0.0
New pending bootp server: 10.10.1.1
>> /cfg/l3/sm/on
>> ServerMobility# add 1 2
Confirm to enable DHCP request filtering on selected ports? [y/n]: y
>> ServerMobility# recovery
>> Server Auto-Recovery# ena
>> Server Auto-Recovery# time 10
>> Server Auto-Recovery# ../port 1
>> Port 1# addback 3
Current backup port: none
New backup port : 3
>> Port 1# ../port 2
>> Port 2# addback 4
Current backup port: none
New backup port : 4
>> Port 2# apply
>> Port 2# save
