BLADE OS 5.1 Application Guide
186 Chapter 11: IGMP BMD00113, September 2009
IGMP Snooping Configuration Example
This section provides steps to configure IGMP Snooping on the GbE2c, using the Command-Line
Interface (CLI).
1. Configure port and VLAN membership on the switch.
2. Turn on IGMP.
3. Add VLANs to IGMP Snooping and enable the feature.
4. Enable IGMPv3 Snooping (optional).
5. Apply and save the configuration.
6. View dynamic IGMP information.
These commands display information about IGMP Groups and Mrouters learned by the switch.
>> /cfg/l3/igmp/on (Turn on IGMP)
>> IGMP Snoop# snoop (Access IGMP Snoop menu)
>> IGMP Snoop# add 1 (Add VLAN 1 to IGMP snooping)
>> IGMP Snoop# ena (Enable IGMP Snooping)
>> IGMP Snoop# igmpv3 (Access IGMPv3 menu)
>> IGMP V3 Snoop# ena (Enable IGMPv3 Snooping)
>> IGMP V3 Snoop# apply (Apply the configuration)
>> IGMP V3 Snoop# save (Save your changes)
>> /info/l3/igmp/dump (Show IGMP Group information)
Note: Local groups (224.0.0.x) are not snooped/relayed and will not appear.
Source Group VLAN Port Version Mode Expires Fwd
-------------- --------------- ------- ------ -------- ----- ------- ---
10.1.1.1 232.1.1.1 2 20 V3 INC 4:16 Yes
10.1.1.5 232.1.1.1 2 20 V3 INC 4:16 Yes
* 232.1.1.1 2 20 V3 INC - No
10.10.10.43 235.0.0.1 9 21 V3 INC 2:26 Yes
* 236.0.0.1 9 21 V3 EXC - Yes
>> /info/l3/igmp/mrouter/dump (Show Mrouter information)
VLAN Port Version Expires Max Query Resp. Time QRV QQIC
------ ------- -------- -------- -------------------- --- ----
1 20 V2 static unknown - -
2 21 V3 4:09 128 2 125
