BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 11: IGMP 189
Configure IGMP Filtering
1. Enable IGMP Filtering on the switch.
2. Define an IGMP filter.
3. Assign the IGMP filter to a port.
>> /cfg/l3/igmp/igmpflt (Select IGMP Filtering menu)
>> IGMP Filter# ena (Enable IGMP Filtering)
Current status: disabled
New status: enabled
>> /cfg/l3/igmp/igmpflt (Select IGMP Filtering menu)
>>IGMP Filter# filter 1 (Select Filter 1 Definition menu)
>>IGMP Filter 1 Definition# range 224.0.1.0 (Enter first IP address of the range)
Current multicast address2:
Enter new multicast address2: 226.0.0.0 (Enter second IP address)
Current multicast address1:
New pending multicast address1: 224.0.1.0
Current multicast address2:
New pending multicast address2: 226.0.0.0
>>IGMP Filter 1 Definition# action deny (Deny multicast traffic)
>>IGMP Filter 1 Definition# ena (Enable the filter)
>> /cfg/l3/igmp/igmpflt (Select IGMP Filtering menu)
>>IGMP Filter# port 20 (Select port 20)
>>IGMP Port 20# filt ena (Enable IGMP Filtering on the port)
Current port 20 filtering: disabled
New port 20 filtering: enabled
>>IGMP Port 20# add 1 (Add IGMP Filter 1 to the port)
>>IGMP Port 20# apply (Make your changes active)
