BLADE OS 5.1 Application Guide
218 Chapter 13: Remote Monitoring BMD00113, September 2009
RMON Group 1—Statistics
The switch supports collection of Ethernet statistics as outlined in the RMON statistics MIB, in
reference to etherStatsTable. You can enable RMON statistics on a per-port basis, and you
can view them using the following command:
/stat/port <x>/rmon
RMON statistics are sampled every second, and new data overwrites any old data on a given port.
Note – RMON port statistics must be enabled for the port before you can view RMON statistics.
RMON Statistics Example
To configure RMON Statistics:
1. Enable RMON on each port where you wish to collect RMON statistics.
2. View RMON statistics for the port.
>> # /cfg/port 20/rmon (Select Port 20 RMON)
>> Port 20 RMON# ena (Enable RMON)
>> Port 20 RMON# apply (Make your changes active)
>> Port 20 RMON# save (Save for restore after reboot)
>> # /stats/port 20 (Select Port 23 Stats)
>> Port Statistics# rmon
------------------------------------------------------------------
RMON statistics for port 23:
etherStatsDropEvents: NA
etherStatsOctets: 7305626
etherStatsPkts: 48686
etherStatsBroadcastPkts: 4380
etherStatsMulticastPkts: 6612
etherStatsCRCAlignErrors: 22
etherStatsUndersizePkts: 0
etherStatsOversizePkts: 0
etherStatsFragments: 2
etherStatsJabbers: 0
etherStatsCollisions: 0
etherStatsPkts64Octets: 27445
etherStatsPkts65to127Octets: 12253
etherStatsPkts128to255Octets: 1046
etherStatsPkts256to511Octets: 619
etherStatsPkts512to1023Octets: 7283
etherStatsPkts1024to1518Octets: 38
