BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 13: Remote Monitoring 223
RMON Events Example
This example configuration creates an RMON event that sends a SYSLOG message each time it is
triggered by an alarm.
1. Configure the RMON Event parameters.
2. Apply and save the configuration.
>> # /cfg/rmon/event 5 (Select RMON Event 5)
>> RMON Event 5# descn "SYSLOG_generation_event"
>> RMON Event 5# type log
>> RMON Event 5# owner "Owner_event_5"
>> RMON Alarm 5# apply (Make your changes active)
>> RMON Alarm 5# save (Save for restore after reboot)
