BLADE OS 5.1 Application Guide
234 Chapter 14: High Availability BMD00113, September 2009
Configuring Layer 2 Failover
Auto Monitor Example
The following procedure pertains to the configuration shown in Figure 27.
1. Configure Network Adapter Teaming on the servers.
2. Define a trunk group on the GbE2c.
3. Configure Failover parameters.
4. Apply and verify the configuration.
5. Save the configuration.
>> # /cfg/l2/trunk 1 (Select trunk group 1)
>> Trunk group 1# add 20 (Add port 20 to trunk group 1)
>> Trunk group 1# add 21 (Add port 21 to trunk group 1)
>> Trunk group 1# add 22 (Add port 22 to trunk group 1)
>> Trunk group 1# add 23 (Add port 23 to trunk group 1)
>> Trunk group 1# ena (Enable trunk group 1)
>> # /cfg/l2/failovr/on (Turn Failover on)
>> Failover# trigger 1 (Select trigger group 1)
>> Trigger 1# ena (Enable trigger group 1)
>> Trigger 1# limit 2 (Set Failover limit to 2 links)
>> Trigger 1# amon (Select Auto Monitor menu)
>> Auto Monitor# addtrnk 1 (Add trunk group 1)
>> Auto Monitor# apply (Make your changes active)
>> Auto Monitor# cur (View current trunking configuration)
>> Auto Monitor# save (Save for restore after reboot)
