BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 14: High Availability 235
Manual Monitor Example
Use the following procedure to configure a Layer 2 Failover Manual Monitor.
1. Configure Network Adapter Teaming on the servers.
2. Configure general Layer 2 Failover parameters.
3. Specify the links to monitor.
4. Specify the links to disable when the failover limit is reached.
5. Apply and verify the configuration.
6. Save the configuration.
>> # /cfg/l2/failovr/on (Turn Failover on)
>> Failover# trigger 2 (Select trigger 2)
>> Trigger 2# ena (Enable trigger 2)
>> Trigger 2# limit 2 (Set Failover limit to 2 links)
>> Trigger 2# mmon/monitor (Select the Monitor menu)
>> Monitor# addport 20 (Add port 20)
>> Monitor# addport 21 (Add port 21)
>> Monitor# addport 22 (Add port 22)
>> Monitor# addport 23 (Add port 23)
>> Monitor# ..
>> Manual Monitor# control (Select the Control menu)
>> Control# addport 1 (Add port 1)
>> Control# addport 1 (Add port 2)
>> Control# apply (Make your changes active)
>> # /cfg/l2/failovr/cur (View current Failover configuration)
>> Failover# save (Save for restore after reboot)
