BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 1: Accessing the Switch 25
Local Management Using the Console Port
Using a null modem cable, you can directly connect to the switch through the console port. A
console connection is required in order to configure Telnet or other remote access applications. For
more information on establishing console connectivity to the switch, see the HP GbE2c Ethernet
Blade Switch User Guide.
The Command Line Interface
The command line interface (CLI) can be accessed via local terminal connection, or from a remote
session using Telnet or SSH. The CLI is the most direct method for collecting switch information
and performing switch configuration.
The GbE2c provides two CLI modes: The menu-based BLADE OS CLI, and the tree-based ISCLI.
You can set the GbE2c to use either CLI mode.
The Main Menu of the BLADE OS CLI, with administrator privileges, is displayed below:
For complete information about the BLADE OS CLI, refer to the BLADE OS 5.1 Command
Reference.
The ISCLI provides a tree-based command structure, for users familiar with similar products. An
example of a typical ISCLI command is displayed below:
For complete information about the ISCLI, refer to the BLADE OS 5.1 ISCLI Reference.
[Main Menu]
info - Information Menu
stats - Statistics Menu
cfg - Configuration Menu
oper - Operations Command Menu
boot - Boot Options Menu
maint - Maintenance Menu
diff - Show pending config changes [global command]
apply - Apply pending config changes [global command]
save - Save updated config to FLASH [global command]
revert - Revert pending or applied changes [global command]
exit - Exit [global command, always available]
Switch(config)# spanning-tree stp 1 enable
