BLADE OS 5.1 Application Guide
34 Chapter 1: Accessing the Switch BMD00113, September 2009
CLI Oper Equivalent
To configure an SNMP user equivalent to the CLI oper, use the following configuration
Configuring SNMP Trap Hosts
SNMPv1 Trap Host
1. Configure a user with no authentication and password.
2. Configure an access group and group table entries for the user. Use the following command to
specify which traps can be received by the user:
/c/sys/ssnmp/snmpv3/usm 5 (Configure the oper)
name "oper"
/c/sys/ssnmp/snmpv3/access 4 (Configure access group 4)
name "opergrp"
rview "oper"
wview "oper"
nview "oper"
/c/sys/ssnmp/snmpv3/group 4 (Assign oper to access group 4)
uname oper
gname opergrp
/c/sys/ssnmp/snmpv3/view 20 (Create views for oper)
name "usr"
tree "1.3.6.1.4.1.1872.2.5.1.2" (Agent statistics)
/c/sys/ssnmp/snmpv3/view 21
name "usr"
tree "1.3.6.1.4.1.1872.2.5.1.3" (Agent information)
/c/sys/ssnmp/snmpv3/view 22
name "usr"
tree "1.3.6.1.4.1.1872.2.5.2.2" (L2 statistics)
/c/sys/ssnmp/snmpv3/view 23
name "usr"
tree "1.3.6.1.4.1.1872.2.5.2.3" (L2 information)
/c/sys/ssnmp/snmpv3/view 24
name "usr"
tree "1.3.6.1.4.1.1872.2.5.3.2" (L3 statistics)
/c/sys/ssnmp/snmpv3/view 25
name "usr"
tree "1.3.6.1.4.1.1872.2.5.3.3" (L3 information)
/cfg/sys/ssnmp/snmpv3/usm 10/name "v1trap"
>> #
/cfg/sys/ssnmp/snmpv3/access <user number>/nview
