BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 1: Accessing the Switch 35
In the example below the user will receive the traps sent by the switch.
3. Configure an entry in the notify table.
4. Specify the IP address and other trap parameters in the targetAddr and targetParam tables.
Use the following command menus:
For example
5. Use the community table to specify which community string is used in the trap.
/c/sys/ssnmp/snmpv3/access 10 (Define access group to view SNMPv1 traps)
name "v1trap"
model snmpv1
nview "iso"
/c/sys/ssnmp/snmpv3/group 10 (Assign user to the access group)
model snmpv1
uname v1trap
gname v1trap
/c/sys/ssnmp/snmpv3/notify 10 (Assign user to the notify table)
name v1trap
tag v1trap
/cfg/sys/ssnmp/snmpv3/taddr <target address index number>
-and-
/cfg/sys/ssnmp/snmpv3/tparam
<target parameter index number>
/c/sys/ssnmp/snmpv3/taddr 10 (Define an IP address to send traps)
name v1trap
addr 47.80.23.245
taglist v1trap
pname v1param
/c/sys/ssnmp/snmpv3/tparam 10 (Specify SNMPv1 traps to send)
name v1param
mpmodel snmpv1
uname v1trap
model snmpv1
/c/sys/ssnmp/snmpv3/comm 10 (Define the community string)
index v1trap
name public
uname v1trap
