BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 1: Accessing the Switch 37
SNMPv3 Trap Host Configuration
To configure a user for SNMPv3 traps, you can choose to send the traps with both privacy and
authentication, with authentication only, or without privacy or authentication.
This is configured in the access table using the following commands:
Configure the user in the user table accordingly.
It is not necessary to configure the community table for SNMPv3 traps because the community
string is not used by SNMPv3.
The following example shows how to configure a SNMPv3 user v3trap with authentication only:
/cfg/sys/ssnmp/snmpv3/access <x>/level
/cfg/sys/ssnmp/snmpv3/tparam <x>
/c/sys/ssnmp/snmpv3/usm 11 (Configure user named “v3trap”)
name "v3trap"
auth md5
authpw v3trap
/c/sys/ssnmp/snmpv3/access 11 (Define access group to view SNMPv3 traps)
name "v3trap"
level authNoPriv
nview "iso"
/c/sys/ssnmp/snmpv3/group 11 (Assign user to the access group)
uname v3trap
gname v3trap
/c/sys/ssnmp/snmpv3/notify 11 (Assign user to the notify table)
name v3trap
tag v3trap
/c/sys/ssnmp/snmpv3/taddr 11 (Define an IP address to send traps)
name v3trap
addr 47.81.25.66
taglist v3trap
pname v3param
/c/sys/ssnmp/snmpv3/tparam 11 (Specify SNMPv3 traps to send)
name v3param
uname v3trap
level authNoPriv (Set the authentication level)
