BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 1: Accessing the Switch 57
To Upload the Configuration to the Switch
Syntax:
Example:
To Apply and Save the Configuration
The apply and save commands are still needed after the last command, or use the following
commands:
The diff command is automatically executed at the end of putcfg to notify the remote
client of the difference between the new and the current configurations.
putcfg_apply runs the apply command after the putcfg is done.
putcfg_apply_save saves the new configuration to the flash after putcfg_apply is
done.
The putcfg_apply and putcfg_apply_save commands are provided because extra
apply and save commands are usually required after a putcfg; however, an SCP session is
not in an interactive mode at all.
SSH and SCP Encryption of Management Messages
The following encryption and authentication methods are supported for SSH and SCP:
Server Host Authentication: Client RSA authenticates the switch at the beginning of every
connection
Key Exchange: RSA
Encryption: 3DES-CBC, DES
User Authentication: Local password authentication, RADIUS, SecurID (via
RADIUS, TACACS+, for SSH only—does not apply to SCP)
scp <local filename> <username>@<switch IP address>:putcfg
>> # scp ad4.cfg scpadmin@205.178.15.157:putcfg
>> # scp ad4.cfg scpadmin@205.178.15.157:putcfg_apply
>> # scp ad4.cfg scpadmin@205.178.15.157:putcfg_apply_save
