BLADE OS 5.1 Application Guide
66 Chapter 2: Ports and Trunking BMD00113, September 2009
Ports on the Switch
The following table describes the Ethernet ports of the switch, including the port name and
function.
Note – The actual mapping of switch ports to server Network Interface Controllers (NICs) is
dependant on the operating system software, the type of server blade, and the enclosure type. For
more information, see the HP GbE2c Ethernet Blade Switch User Guide.
Table 7 Ethernet Switch Port Names
Port Number Port Name Port Number Port Name
1 Downlink1 13 Downlink13
2 Downlink2 14 Downlink14
3 Downlink3 15 Downlink15
4 Downlink4 16 Downlink16
5 Downlink5 17 XConnect1
6 Downlink6 18 XConnect2
7 Downlink7 19 Mgmt
8 Downlink8 20 Uplink1
9 Downlink9 21 Uplink2
10 Downlink10 22 Uplink3
11 Downlink11 23 Uplink4
12 Downlink12 24 Uplink5
