BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 2: Ports and Trunking 75
Configuring LACP
Use the following procedure to configure LACP for port 20 and port 21 to participate in link
aggregation.
1. Set the LACP mode on port 20.
2. Define the admin key on port 20. Only ports with the same admin key can form a LACP trunk
group.
3. Set the LACP mode on port 21.
4. Define the admin key on port 21.
5. Apply and verify the configuration.
6. Save your new configuration changes.
>> # /cfg/l2/lacp/port 20 (Select port 20)
>> LACP port 20# mode active (Set port 20 to LACP active mode)
>> LACP port 20# adminkey 100 (Set port 20 adminkey to 100)
Current LACP port adminkey: 17
New pending LACP port adminkey: 100
>> # /cfg/l2/lacp/port 21 (Select port 21)
>> LACP port 21# mode active (Set port 21 to LACP active mode)
>> LACP port 21# adminkey 100 (Set port 21 adminkey to 100)
Current LACP port adminkey: 18
New pending LACP port adminkey: 100
>> LACP port 21# apply (Make your changes active)
>> LACP port 21# cur (View current trunking configuration)
>> LACP port 21# save (Save for restore after reboot)
