BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 3: Port-Based Network Access Control 83
80 Message-
Authenticator
Always present whenever an EAP-Message
attribute is also included. Used to
integrity-protect a packet.
1111
87 NAS-Port-ID Name assigned to the authenticator port, e.g.
Server1_Port3
1000
Legend:
RADIUS Packet Types:
A-R (Access-Request), A-A (Access-Accept), A-C (Access-Challenge), A-R (Access-Reject)
RADIUS Attribute Support:
0 This attribute MUST NOT be present in a packet.
0+ Zero or more instances of this attribute MAY be present in a packet.
0-1 Zero or one instance of this attribute MAY be present in a packet.
1 Exactly one instance of this attribute MUST be present in a packet.
1+ One or more of these attributes MUST be present.
Table 9 Support for RADIUS Attributes
# Attribute Attribute Value A-R A-A A-C A-R
