BLADE OS 5.1 Application Guide
BMD00113, September 2009 Chapter 4: VLANs 89
The default configuration for the switch sets all ports (except the management port) as untagged
members of VLAN 1, and sets the PVID to 1. In the default configuration example, all incoming
packets are assigned to VLAN 1 by the default port VLAN identifier (PVID=1).
Use the following CLI commands to view PVIDs:
Use the following command to configure PVIDs:
Each port on the switch can belong to one or more VLANs, and each VLAN can have any number
of switch ports in its membership. Any port that belongs to multiple VLANs, however, must have
VLAN tagging enabled (see “VLAN Tagging” on page 90).
Any untagged frames (those with no VLAN specified) are set with the PVID of the sending port.
>> # /info/port
Port Tag MediaRMON Lrn Fld PVID NAME VLAN(s)
---- --- ---- --- --- ----- -------------- ----------------------------
1 n Auto d e e 1* Downlink1 1
2 n Auto d e e 1* Downlink2 1
3 n Auto d e e 1* Downlink3 1
4 n Auto d e e 1* Downlink4 1
5 n Auto d e e 1* Downlink5 1
6 n Auto d e e 1* Downlink6 1
7 n Auto d e e 1* Downlink7 1
8 n Auto d e e 1* Downlink8 1
9 n Auto d e e 1* Downlink9 1
10 n Auto d e e 1* Downlink10 1
11 n Auto d e e 1* Downlink11 1
12 n Auto d e e 1* Downlink12 1
13 n Auto d e e 1* Downlink13 1
14 n Auto d e e 1* Downlink14 1
15 n Auto d e e 1* Downlink15 1
16 n Auto d e e 1* Downlink16 1
17 n Auto d e e 1* Xconnect1 1
18 n Auto d e e 1* Xconnect2 1
19 n Auto d e e 4095 Mgmt 4095
20 n Auto d e e 1* Uplink1 1
21 n Auto d e e 1* Uplink2 1
22 n Auto d e e 1* Uplink3 1
23 n Auto d e e 1* Uplink4 1
24 n Auto d e e 1* Uplink5 1
* = PVID is tagged.
>> /cfg/port <port number>/pvid <PVID number>
