Ethernet Support Guide (for HP-UX 11i v1, 11i v2)
Table Of Contents
- About This Manual
- 1 Introduction to Technology
- 2 Installation and Configuration
- 3 Administration
- Gigabit-Specific Information
- Logging and Auditing
- Detailed Configuration Information
- Understanding the Gigabit Ethernet Parameters
- Using the lanadmin Tool with Gigabit Ethernet
- Performance and Tuning Considerations
- Fast Ethernet-Specific Information
- 4 Troubleshooting
- Troubleshooting Overview
- Diagnostic Flowcharts
- Flowchart 1: Cable and LED Test
- Flowchart 2: Link Level Test
- Flowchart 3: Network Level Tests
- Flowchart 4: ARP Test
- Flowchart 5: ping Test
- Flowchart 5 (continued)
- Flowchart 6: Transport Level Test
- Flowchart 7: Bridge/Gateway Loopback Test
- Flowchart 8: Configuration Tests
- Flowchart 9: ioscan and lanscan Tests
- Flowchart 10: netfmt and lanadmin Tests
- Flowchart 11: ifconfig Test
- Network Level Test for Jumbo Frames (Gigabit Ethernet only)
- Ethernet-Specific Information
- Contacting Your HP Representative
- A Technical Specifications
- Gigabit Ethernet
- The Meaning of the LEDs
- Card Specifications
- A4924A / A4925A / A4926A Specifications
- A4929A Specifications
- A6825A/A6847A Specifications
- Fast Ethernet
- PCI-X 10/100Base-TX card Specifications
- One-Port cards (B5509AA/A5230A)
- Four-Port card (A5506A)
- B Cabling Requirements
- Gigabit Ethernet
- Connectors
- Cabling
- Back-to-Back Connection
- 10/100Base-TX Ethernet
- Connectors
- PCI-X 10/100Base-TX card Twisted-Pair Connector
- Connector Pin Usage for 10- Mbit/s Twisted-Pair Connector
- FigureB1 Pin Layout of RJ-45 Connector on PCI-X Card
- Connector Pin Usage for 100- Mbit/s Twisted-Pair Connector
- Cabling
- C Worksheets
- Gigabit Ethernet Worksheets
- Network Card Configuration Worksheet
- D Card Statistics
- Glossary
Installation and ConfigurationInstallation OverviewChapter 224Installation OverviewInstalling Fast Ethernet or Gigabit Ethernet cards consists of the following steps:• Power down your system, or card section (if applicable)• Insert the card in the card cage• Power up your system, or card section (if applicable)• Install the appropriate driver(s) if necessary.• Configure the card• Verify the installationThis chapter provides detailed instructions to install and configure your card.For detailed help in resolving installation, configuration and operational problems, seeChapter 4, “Troubleshooting,” on page 47.Create a Record or Map of Your InternetworkBe sure to create or update a record of your network and internetwork before attemptinginstallation. You may find the Ethernet Card Configuration Worksheet in the appendixhelpful for this. You can also create a map showing how pieces of your internetwork arerelated. Your records should include the following:• Approximate dimensions of the building or room containing the Ethernet network• Location of routers, bridges and gateways• Location of nodes and node connections• Location of network segments and subnets within each segment• Hostname of each node• Internet address and alias of each node (in the case of gateways, each Ethernet cardhas its own Internet address and alias)• Hardware path of each card in the system, including Ethernet cards (you can usethis information as part of a disaster recovery plan)• Version number of the operating system installed on each node
