Troubleshooting

Ethernet-Speciﬁc Information

Chapter 4

71

Ethernet-Speciﬁc Information

This section provides references to information and useful tools for installing,

conﬁguring and maintaining Ethernet products.

Error Messages

Gigabit Ethernet comes with an online message catalog that is used to report

networking problems. You must use the nettl logging and tracing utility to display the

probable cause and action for a message.

Logging Messages

Ethernet uses the nettl(1M) logging and tracing facility supplied with HP-UX. You

may access the logging and tracing utility using either the graphical user interface (GUI)

version or the command-line interface. The names of the log ﬁles produced by NetTL are:

• For releases prior to HP-UX 11i: nettl.LOG-00 and nettl.LOG-01

• For release HP-UX 11i and later: nettl.LOG000 and nettl.LOG001

Features of the GUI version, which are now a part of your HP system, include:

• An interface that guides you through logging and tracing tasks

• An interface that allows you to create and format reports

• The capability to collect logging and tracing subsystem-speciﬁc information

• Report screens that are updated instantaneously with current logging and tracing

information by the subsystem

• Context-sensitive online help

To access the GUI version of the logging and tracing utility, enter:

$ nettladm

See the nettladm(1M) manpage for information on using the GUI version, or the

nettl(1M) manpage for information on using the command-line interface.

Listed below are some example commands using the command-line interface. Note that

these examples apply only to HP-UX 11i, or later.

• To examine the log ﬁle with cause and action descriptions, enter:

$ netfmt -v -f /var/adm/nettl.LOG000 | more

The -v option enables the reporting of available cause and action descriptions for

each log message. A sample log message using the -v option follows:

***********Gigabit Ethernet LAN Networking***********

Timestamp : Mon Aug 3 PDT 1998 18:37:16.175754

Process ID : [ICS] Subsystem:GELAN

User ID ( UID ) : -1 Log Class:DISASTER

Device ID : 3 Path ID: 0

Connection ID : 0 Log Instance: 0
