Gigabit Ethernet
This section provides technical specifications for Gigabit Ethernet cards.
The Meaning of the LEDs
The Link LED indicates the card’s status and must be on for the card to function
properly. Note that there is no Link LED on the 1000Base-T card. In its place are three
LEDs that indicate what speed (10, 100, or 1000 Mbit/s) the link has been established.
The following tables show the LED description and status for the 1000Base-SX (Table
A-1) and 1000Base-T (Table A-2).
Table A-1 LED Description and Status for 1000Base-SX
LED Description
and Color
On (Steady) Flashing Off
Link - Green Good connection
between card and
network at 1000
Mbit/s.
Port disabled by
software,
connection failed,
or card trying to
establish
connection.
Note: A6847A is
not programmed
to flash the Link
LED.
No connection
between card
and network.
ACT (Activity) -
Amber
Data detected Data detected No data detected
Table A-2 LED Description and Status for 1000Base-T
LED Description
and Color
On (Steady) Flashing Off
1000 - Green
100 - Green
10 - Green
Note: Only one
speed LED should
be on at any given
time.
Good connection
between card and
network at either 10,
100, or 1000 Mbit/s as
indicated by LED.
Note: For A4929A, if
all Link speed LEDs
are on steady, the
driver is disabled or
not installed.
The 1000 Mbit/s
LED will flash
when the card is
trying to establish
a connection.
No connection
between card
and network.
