Technical Specifications
Fast Ethernet
Appendix A
82
Fast Ethernet
PCI-X 10/100Base-TX card Specifications
The following tables provide the physical, electrical, environmental and electromagnetic
compatibility specifications for the PCI-X 10/100Base-TX cards.
One-Port cards (B5509AA/A5230A)
Four-Port card (A5506A)
NOTE Due to CPU limitations in A-class systems, maximum throughput cannot be achieved on
all ports.
Table A-21 B5509AA / A5230A Physical Specifications
Dimensions (B5509AA
and A5230A):
5.075 in by 3.9 in
Table A-22 B5509AA / A5230A Electrical Specifications
Power requirement: +5.Volts @ 1.5 amps max
Table A-23 B5509AA / A5230A Environmental Specifications
Operating temperature: 0o C to 50o C
Storage temperature 0o C to 55o C ambient
Shipping environment -40o C to 70o C ambient
Relative humidity: 5% to 85% non-condensing
Table A-24 B5509AA / A5230A Electromagnetic Compatibility Specs
FCC part 15 Class B USA, Canada and Latin America
CISPR-22 Class A
EN55022 Class A
Europe
VCCI Class A Japan
Table A-25 A5506A Physical Specifications
Dimensions (A5506A): 12 in by 4.2 in (conforms to PCI-X Long
card specification)
Table A-26 A5506A Electrical Specifications
Power requirement: +5.Volts @ 3.5 amps max
