Gigabit Ethernet Worksheets
This section contains a user worksheet for Gigabit Ethernet cards. Worksheets are
presented, one worksheet to a page, so that you may easily make working copies for
installation, configuration or operation of the product. The worksheets included are:
• Ethernet card Configuration Worksheet
Network Card Configuration Worksheet
Fill out one worksheet for each network card you are installing.
Table C-1 Ethernet Card Configuration Worksheet
Data Type
Require
d/
Optional
Default
How to
Configure (see
Note 1)
Example
Your
System
Internet
Address
Required 0.0.0.0 SAM or ifconfig
or edit
/etc/rc.config.
d/netconf
196.6.20.2
Subnet mask Required
if using
subnettin
g
Subnet
mask not
used
SAM or ifconfig
or edit
/etc/rc.config.
d/netconf
255.255.248.0
Station
address
Built-in
but can be
optionally
changed
As shown
on card
SAM or edit
/etc/rc.config.
d/hpietherconf
or temporarily:
lanadmin -A
0x0060b0c4012f
Host name
alias for this
network
interface
(card)
Required
if the
system is
connected
to more
than 1
network
None SAM or edit
/etc/hosts
host1
Link
configuration
Required Autoneg-
otiating
SAM or
temporarily:
lanadmin -X
lanadmin -X
auto_on ppa#
(if already
turned off)
Link
speed/duplex
mode
Required Autoneg-
otiating
Hub or switch
(see Note 2) SAM
or temporarily:
lanadmin -X
lanadmin -X
100fd ppa#
