110
The TTL value of a state-refresh message decrements by 1 whenever it passes a router before it is
forwarded to the downstream node until the TTL value comes down to 0. In a small network, a
state-refresh message might cycle in the network. To effectively control the propagation scope of
state-refresh messages, configure an appropriate TTL value based on the network size.
Perform the following configurations on all routers in the PIM domain.
To configure state-refresh parameters:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter public network PIM view or
VPN instance PIM view.
pim [ vpn-instance
vpn-instance-name ]
N/A
3. Configure the interval between
state-refresh messages.
state-refresh-interval interval
Optional.
60 seconds by default.
4. Configure the time to wait before
receiving a new state-refresh
message.
state-refresh-rate-limit interval
Optional.
30 seconds by default.
5. Configure the TTL value of
state-refresh messages.
state-refresh-ttl ttl-value
Optional.
255 by default.
Configuring PIM-DM graft retry period
In PIM-DM, graft messages are the only type of messages that involve the acknowledgment mechanism.
In a PIM-DM domain, a router sends a graft message to an upstream router. If the router does not receive
a graft-ack message from the upstream router within the specified time, the router send new graft
messages at a configurable interval (called a graft retry period). The router will keep sending graft
messages until it receives a graft-ack message from the upstream router.
To configure the graft retry period:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure the graft retry
period.
pim timer graft-retry interval
Optional.
3 seconds by default.
For more information about the configuration of other timers in PIM-DM, see "Configuring common PIM
timers."
Configuring PIM-SM
This section describes how to configure PIM-SM.
PIM-SM configuration task list
