R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

131
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter public network PIM view
or VPN instance PIM view.
pim [ vpn-instance
vpn-instance-name ]
N/A
3. Configure a C-BSR for an
admin-scope zone.
c-bsr group group-address { mask |
mask-length } [ hash-length
hash-length | priority priority ] *
No C-BSRs are configured for an
admin-scope zone by default.
The group-address { mask |
mask-length } argument can
specify the multicast groups that
the C-BSR serves, in the range of
239.0.0.0/8.
2. Configure C-BSRs for the global-scope zone
Perform the following configuration on the routers that you want to configure as C-BSRs in the
global-scope zone.
To configure a C-BSR for the global-scope zone:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter public network PIM view
or VPN instance PIM view.
pim [ vpn-instance
vpn-instance-name ]
N/A
3. Configure a C-BSR for the
global-scope zone.
c-bsr global [ hash-length
hash-length | priority priority ] *
No C-BSRs are configured for the
global-scope zone by default.
Configuring PIM-SSM
PIM-SSM needs the support of IGMPv3. Be sure to enable IGMPv3 on PIM routers with multicast
receivers.
PIM-SSM configuration task list
Complete these tasks to configure PIM-SSM:
Task Remarks
Enabling PIM-SM Required.
Configuring the SSM group range Optional.
Configuring common PIM features Optional.
Configuration prerequisites
Before you configure PIM-SSM, complete the following tasks:
• Configure any unicast routing protocol so that all devices in the domain are interoperable at the
network layer.
• Determine the SSM group range.
