Configuring the SSM group range
Whether the PIM-SSM model or the PIM-SM model delivers the information from a multicast source the
receivers depends on whether the group address in the (S, G) packets that the receivers request is in the
SSM group range. All PIM-SM-enabled interfaces assume the PIM-SSM model for multicast groups within
this address range.
Configuration guidelines
• Perform the following configuration on all routers in the PIM-SSM domain.
• Make sure the same SSM group range is configured on all routers in the entire domain. Otherwise,
multicast information cannot be delivered through the SSM model.
• When a member of a multicast group in the SSM group range sends an IGMPv1 or IGMPv2 report
message, the device does not trigger a (*, G) join.
Configuration procedure
To configure an SSM multicast group range:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter public network PIM view
or VPN instance PIM view.
pim [ vpn-instance
vpn-instance-name ]
N/A
3. Configure the SSM group
range.
ssm-policy acl-number
Optional.
232.0.0.0/8 by default.
Configuring common PIM features
For the configuration tasks in this section, the following rules apply:
• The configurations made in PIM view are effective on all interfaces. The configurations made in
interface view are effective only on the current interface.
• A configuration made in interface view always has priority over the same configuration made in
PIM, regardless of the configuration sequence.
Configuration task list
Task Remarks
Configuring a multicast data filter Optional.
Configuring a hello message filter Optional.
Configuring PIM hello options Optional.
Setting the prune delay timer Optional.
Configuring common PIM timers Optional.
Configuring join/prune message sizes Optional.
Configuring PIM to work with BFD Optional.
