manage multicast group memberships on stub subnets with attached group members. A multicast
router itself can be a multicast group member.
For a better understanding of the multicast concept, you can compare multicast transmission to the
transmission of TV programs.
Table 1 Comparing TV program transmission and multicast transmission
TV program transmission Multicast transmission
A TV station transmits a TV program through a
channel.
A multicast source sends multicast data to a multicast
group.
A user tunes the TV set to the channel. A receiver joins the multicast group.
The user starts to watch the TV program transmitted
by the TV station through the channel.
The receiver starts to receive the multicast data that the
source is sending to the multicast group.
The user turns off the TV set or tunes to another
channel.
The receiver leaves the multicast group or joins another
group.
Common notations in multicast
The following notations are commonly used in multicast transmission:
• (*, G)—Rendezvous point tree (RPT), or a multicast packet that any multicast source sends to
multicast group G. Here, the asterisk represents any multicast source, and "G" represents a specific
multicast group.
• (S, G)—Shortest path tree (SPT), or a multicast packet that multicast source S sends to multicast
group G. Here, "S" represents a specific multicast source, and "G" represents a specific multicast
group.
For more information about the concepts RPT and SPT, see "Configuring PIM" and "Configuring IPv6
PIM."
Multicast advantages and applications
The multicast technique has the following advantages:
• Enhanced efficiency—Reduces the processor load of information source servers and network
devices.
• Optimal performance—Reduces redundant traffic.
• Distributed application—Enables point-to-multipoint applications at the price of minimum network
resources.
The multicast technique can be use for the following applications:
• Multimedia and streaming applications, such as web TV, web radio, and real-time video/audio
conferencing
• Communication for training and cooperative operations, such as distance learning and
telemedicine
• Data warehouse and financial applications (stock quotes)
• Any other point-to-multipoint application for data distribution
