R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

209
Table 8 Description of the both, send, and receive parameters and the negotiation result
Local
p
arameter Peer
p
arameter Ne
g
otiation result
send
• receive
• both
The ORF sending capability is enabled locally and
the ORF receiving capability is enabled on the
peer.
receive
• send
• both
The ORF receiving capability is enabled locally and
the ORF sending capability is enabled on the peer.
both both
Both the ORF sending and receiving capabilities
are enabled locally and on the peer.
Configuring the maximum number of MBGP routes for load
balancing
Step Command Remarks
1. Enter system view.
system-view N/A
2. Enter BGP view. bgp as-number N/A
3. Enter IPv4 MBGP address
family view.
ipv4-family multicast N/A
4. Configure the maximum
number of MBGP routes for
load balancing.
balance [ ebgp | ibgp ] number Not configured by default.
Configuring a large scale MBGP network
Configuration prerequisites
Before you configure this task, you must make peering nodes accessible to each other at the network
layer.
Configuring IPv4 MBGP peer groups
In a large-scale network, configuration and maintenance become difficult due to large numbers of MBGP
peers. You can configure peer groups to make management easier and improve route distribution
efficiency.
IMPORTANT:
• To configure an MBGP peer group, you must enable the correspondin
g
IPv4 BGP unicast peer
g
roup in
IPv4 MBGP address family view.
• Before adding an MBGP peer to an MBGP peer group, you must add the corresponding IPv4 unicast
peer to the IPv4 BGP peer group.
To configure an IPv4 MBGP peer group:
