R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

210
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter BGP view.
bgp as-number N/A
3. Create a BGP peer group.
group group-name [ external |
internal ]
Not created by default.
4. Add a peer into the peer
group.
peer ip-address group group-name
[ as-number as-number ]
No peer added by default.
5. Enter IPv4 MBGP address
family view.
ipv4-family multicast N/A
6. Enable the IPv4 unicast peer
group.
peer group-name enable N/A
7. Add an IPv4 MBGP peer to
the peer group.
peer ip-address group group-name Not configured by default.
Configuring MBGP community
The community attribute can be advertised between MBGP peers in different ASs. Routers in the same
community share the same policy.
You can reference a routing policy to modify the community attribute for routes sent to a peer. In addition,
you can define extended community attributes as needed.
When you configure MBGP community, you must reference a routing policy to define the specific
community attributes, and apply the routing policy for route advertisement.
For routing policy configuration, see Layer 3—IP Routing Configuration Guide.
To configure MBGP community:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter BGP view.
bgp as-number N/A
3. Enter IPv4 MBGP address
family view.
ipv4-family multicast N/A
4. Advertise the community
attribute to an MBGP peer or a
peer group.
• Advertise the community attribute
to an MBGP peer or a peer group:
peer { group-name | ip-address }
advertise-community
• Advertise the extended community
attribute to an MBGP peer or a
peer group:
peer { group-name | ip-address }
advertise-ext-community
Use either method.
Not configured by default.
5. Apply a routing policy to
routes advertised to an MBGP
peer or a peer group.
peer { group-name | ip-address }
route-policy route-policy-name export
Not configured by default.
