R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

213
Task Command Remarks
Display IPv4 MBGP routing
information sent to or received
from an MBGP peer.
display bgp multicast routing-table peer
ip-address { advertised-routes |
received-routes } [ network-address [ mask |
mask-length ] | statistic ] [ | { begin | exclude |
include } regular-expression ]
Available in any view.
Display IPv4 MBGP routing
information matching an AS
regular expression.
display bgp multicast routing-table
regular-expression as-regular-expression
Available in any view.
Display IPv4 MBGP routing
statistics.
display bgp multicast routing-table statistic [ |
{ begin | exclude | include }
regular-expression ]
Available in any view.
Resetting MBGP connections
Task Command Remarks
Reset specified MBGP
connections.
reset bgp ipv4 multicast { all |
as-number | ip-address | group
group-name | external | internal }
Available in user view.
Clearing MBGP information
Task Command Remarks
Clear dampened routing
information and release
suppressed routes.
reset bgp ipv4 multicast dampening
[ ip-address [ mask | mask-length ] ]
Available in user view.
Clear MBGP route flap
statistics.
reset bgp ipv4 multicast flap-info
[ regexp as-path-regexp |
as-path-acl as-path-acl-number |
ip-address [ mask | mask-length ] ]
Available in user view.
MBGP configuration example
Network requirements
PIM-SM 1 is in AS 100, and PIM-SM 2 is in AS 200. OSPF is the IGP in the two ASs, and MBGP runs
between the two ASs to exchange multicast route information. The multicast source belongs to PIM-SM 1,
and the receiver belongs to PIM-SM 2. Configure the respective Loopback 0 of Router A and Router B as
the C-BSR and C-RP of the respective PIM-SM domains. Set up an MSDP peer relationship between
Router A and Router B through MBGP.
