235
• Determine the address ranges of switch-group-pools and ACL rules for MDT switchover.
• Determine the switch-delay period.
• Determine the switch-holddown period.
Enabling IP multicast routing in a VPN instance
Before you configure any MD-VPN functionality for a VPN, you must enable IP multicast routing in the
VPN instance.
To enable IP multicast routing in a VPN instance:
Ste
p
Command
Remarks
1. Enter system view.
system-view N/A
2. Create a VPN instance and
enter VPN instance view.
ip vpn-instance vpn-instance-name
N/A
For more information about this
command, see MPLS Command
Reference.
3. Configure an RD for the VPN
instance.
route-distinguisher
route-distinguisher
No RD is configured for a VPN
instance by default.
For more information about this
command, see MPLS Command
Reference.
4. Enable IP multicast routing. multicast routing-enable Disabled by default.
Configuring a share-group and an MTI binding
By running multiple instances on each PE device, you enable the PE device to work for multiple VPNs. You
must configure the same share-group address for the same VPN instance on different PE devices. With a
share-group and an MTI number configured, the system automatically creates an MTI, binds the
share-group address to the MTI, and binds the MTI to the current VPN instance.
Configuration guidelines
• After a BGP peer is configured with the peer connect-interface command, the MTI interface
automatically obtains the connect-interface address and uses it as its own IP address. This IP
address cannot be used in the VPN network any more. Otherwise the MTI interface will fail to
obtain an IP address. When configuring multiple BGP peers on the same device, you must specify
the same connect-interface address for these BGP peers. Otherwise the MTI interface will also fail
to obtain an IP address, either. For more information about the peer connect-interface command,
see Layer 3—IP Routing Command Reference.
• PIM on the MTI interface takes effect only after PIM is enabled on at least one interface of the VPN
instance. When PIM is disabled on all the interfaces of the VPN instance, PIM on the MTI interface
is disabled simultaneously.
Configuration procedure
To configure a share-group and an MTI binding:
Ste
p
Command
Remarks
1. Enter system view. system-view N/A
